Black Aluminium Checker Plate

Product Detail

Black Aluminium Checker Plate Specification:

Alloy: 1050, 1060, 1070, 3003, 5052, 3105, 6061
Patterns:Two bar,three bar,Five bar
bars height: 0.8-1.3mm
thickness:0.8-10.0mm
width: 800-1800mm
length: 800-12000mm



Black Aluminium Checker Plate Chemical Requirements:

Alloy	Si	Fe	Cu	Mn	Mg	Cr	Ni	Zn	Ti	Al
1060	0.25	0.35	0.05	0.03	0.03	---	---	0.05	0.03	99.6
1050	0.25	0.4	0.05	0.05	0.05	---	---	0.05	0.03	99.5
1100	0.95		0.05-0.2	0.05	---	---	---	0.1	---	99.0
1200	1.0		0.05	0.05	---	---	---	0.1	0.05	99.0
3003	0.6	0.7	0.05-0.2	1.0-1.5	---	---	---	0.1	---	remainder



Black Aluminium Checker Plate Application:

Vehicle
Characteristics and benefits: light weight transport sector is required, the best comer of an aluminum alloy step. Increase the energy-saving effect.
Applications: checker plate floor, such as van-type vehicle catwalk flooring, wood step of the bus or truck, train inspection hole lid, tank car, the car cold storage.
Plant
Characteristics and benefits: harmless because it is also suitable for container species, such as facilities and chemical plants and food plant is excellent in chemical resistance.
Applications: bench floor and stairs, equipment/ plant machinery, such as ambulatory inspection.
